Varied Editions — Torcello

I mentioned in an earlier blog that some motifs inspire experimentation, and these images of S. Maria Assunta on the Venetian island of Torcello are examples of one group of techniques used to add colour to an image.

First, proofs are taken at each stage in black ink until the plate is considered to be completed. Then, by carefully inking-up à la poupée and selective wiping and/or rolling of the plate, a wide range of weather and lighting conditions, can be suggested with coloured inks. It is great fun to do, not least because the resulting prints can be unpredictable.

The plate may be inked in two or more colours. Sometimes it may be passed a second time through the press. If it does have a second pass, then the registration of the plate is crucial in achieving a crisp image.

Sometimes the plate is printed onto a new sheet of paper without re-inking. This is called a muculature, or ghost print and can produce a wonderful, soft, atmospheric image.

Using these techniques takes a lot more time and care than inking in black.

A unique inking of a plate is known as a varied edition, usually shown on the print as (VE) sometimes called a monoprint.

Here is a selection from 3 plates, showing how different the motif can look with this technique.

This slideshow requires JavaScript.



This slideshow requires JavaScript.



This slideshow requires JavaScript.

©Henry Hagger 2019

Lithography: on stone and metal

In past blogs, I have shown examples of various forms of etching. In this one, I’ll talk about a completely different form of printmaking – lithography. Of all the printing techniques, lithography comes closest to painting in the marks that can be made.

Etching is an intaglio technique where the image is recessed into a plate. In lithography, the image is drawn onto a prepared flat surface with a greasy material and depends on the incompatibility of water and this grease. The greasy marks of the drawing can be made with crayons, special inks and diluted washes of grease-based materials applied with a nib or brush.

A stone can also be etched with acid, engraved or photo-sensitised.

Bavaria has the finest quality of fine-grained limestone in the world and it was here that Alois Sennefelder discovered the process of lithography in 1793. His experiments showed that by chemically treating the greasy marks of a drawing made on the stone, they could be made to accept printing ink while the areas with no drawing would, if dampened with water, stay ink-free.

The stones are usually about 3–4 inches thick, and therefore extremely heavy. The first stage of preparation is to remove any existing image on the stone by grinding it away with grit, and then polishing the whole surface with water of Ayr (a very hard stone) to remove any scratches. Next, the artist, choosing a size of grit suitable for the delicacy of the image, grains the surface of the stone with carborundum grit. The stone is then prepared for drawing by treating it with acetic acid. The image is drawn directly onto the stone, then treated with a mixture of gum arabic and nitric acid; and then left overnight to ‘cure’.

After several more operations, a non-setting ink is rolled onto the stone and proofed up to five times onto newsprint to achieve full strength of the image. If no alterations or adjustments are necessary, the stone is treated again with the gum-acid mixture and, after a further hour, the edition may be printed. Hand-made paper is carefully placed over the stone and above this, you place a make-ready of newsprint – to ensure an even surface. The stone, with paper in place, is wound through the special lithographic press and then the resulting print is hung up to dry.

This slideshow requires JavaScript.

Once the printing of the edition is complete, the image will be erased from the stone by grinding it away, and thus the stone can be re-used over and over. All this grinding is done by hand, using a heavy steel device called a levigator and lots of water. It’s a very physical and messy business.

The technique was very popular in the nineteenth century for producing posters. Much of Toulouse Lautrec’s work was produced using this technique. It was normal to use several colours for these posters, each one requiring a separate stone. They were always printed by specialist workshops.

The more recent availability of pre-textured zinc and aluminium plates widens the scope of the technique and also allows for printing on a normal etching press. Printing from these plates uses similar techniques to printing from stone but is less arduous. The plates can be re-used up to five times before re-graining by a specialist becomes necessary. Together with the stones, each surface offers the artist its own advantages and limitations.

I have shown examples of lithographs taken from stones, from zinc, and also from aluminium plates. Sometimes, I have added to the print: by drawing with charcoal or pastel; by monoprinting over the lithograph from a separate sheet; or by adding watercolour. There is also an example of a lithograph printed on chine collé.

The stone of St. David‘s Cathedral was drawn with lithographic crayons in varying degrees of hardness and with lithographic ink applied with a dip pen.

The lightning in the print of Torcello shows an example of a mark made by engraving into the stone. You couldn’t make this mark on a lithographic plate.

OLYMPUS DIGITAL CAMERA
Torcello – lithograph on stone (see stone marks around the edge)

S. Giorgio Maggiore is a two-plate lithograph. The Blue plate was drawn/painted with tusche mixed with distilled water.

OLYMPUS DIGITAL CAMERA
San Giorgio Maggiore: two-plate lithograph with added pastel
OLYMPUS DIGITAL CAMERA
San Giorgio Maggiore: the Blue plate























As you can gather, preparing and printing a lithograph takes time and physical effort but it does produce results, which are different to intaglio.

This slideshow requires JavaScript.



©Henry Hagger 2019

Exhibition: Society of Artists in Architecture

Four of my prints are included in

an exhibition by the Society of Artists in Architecture:

viewing from 19 April–4 June 2019,

University College Hospital
235 Euston Road,
London, NW1 2BU
Tel. 07948 015 314

NB: The pictures, including mine, are not all ‘architectural’

(Ground Floor, near the Café)

©Henry Hagger 2019

Henry’s Open Studio: 1–2 December 2018

In December 2018, I have organised an Open Studio weekend, at my very peaceful studio in the Park of Alexandra Palace.

Henry’s Open Studio

Etchings and Lithographs in B&W and colour

Editioned prints and working proofs

Pastels and watercolours

viewing: Saturday 1 December and  Sunday 2 December 2018**

Open: 11am–4pm

Henry’s Studio in Alexandra Palace Park,
London N10 2AS (nearest Satnav*)
My mobile: 07948 015 314

RSVP: henryhaggerstudio@gmail.com

Open Studio 2018 invite and map

  • *Please download a copy of the map attached to help you find the studio, which is near ‘the Grove’, inside the park. Just click on the map to download and print it.
  • ** Weekend parking can be difficult, to avoid this, park near the intersection of Dukes Avenue and Grove Avenue, and enter via that entrance, for the shortest walk to my Studio.

©Henry Hagger 2018

Hastings: Dawn and Dusk

Here are two sides of Hastings: the fishing community at Rock-a-Nore and the trippers on the sands.

This slideshow requires JavaScript.



Dawn is printed from a steel plate and uses the techniques of soft ground, aquatint, spit-bite, scraping, burnishing and dry-point.

As you can see, it went through several transformations, most notably at State 5 when there were five separate stoppings-out. After each stopping-out, the plate is placed back in the acid for a predetermined time. The time for each biting is different and the effect is cumulative. You can also see the effect of different wiping of the same state in images 3, 3a and 3b.

There is much scraping-out on this plate, which is a difficult job because steel is much harder than zinc. Steel, however, is better for colours, especially yellows, which, when wiped on zinc plates often take on a greenish hue.

In State 7, I have experimented with colour. These prints are monoprints (sometimes referred to as V.E. or varied edition), that is, they are variations printed from the same matrix: each one is unique.

Hastings state 6 monoprint 1 plate wiped in black and rolled in yellow 72dp
VE 1  © Henry Hagger
Hastings state 6 monoprint 2 plate wiped in Umber and rolled in yellow72dpi
VE 2 © Henry Hagger
Hastings state 6 monoprint 3 plate wiped in black and rolled in yellow 72dpi
VE 3 © Henry Hagger
Hastings state 6 monoprint 4 wiped in black with orange roll 72dpi
VE 4 © Henry Hagger
Hastings state 6 monoprint 5 wiped in black with pale orange roll 72dpi
VE 5 © Henry Hagger

I used a different technique to the à la poupée that I showed you in Spanish Journey: Part IV: Ronda and Madrid. Here the dark ink is wiped into the intaglio and the lighter colour, which may be modified to alter its consistency or viscosity, is applied over the plate with a roller. Thus, when printed, the dark ink is the top layer.

I was particularly attracted by the foremost boat, RX55. Clinker-built boats have such graceful lines and, in the round, are beautifully crafted sculpture.

There is no harbour at Hastings and the fishing boats are pulled up onto the beach by a big tractor. Boats are registered at the nearby port of Rye, hence the RX numbers on their prow.

Old tales, young dreams, intaglio gravure, 300 dpi RSMA 2014, SocAA2017 , Discerning Eye 2016
Old Tales, Young Dreams © Henry Hagger

The Dusk plate is intaglio gravure wiped in a blue/black blend to give an impression of the sea at dusk.

A father and his children sit on the shingle, with the Hastings Pier in the background. He appears to be telling a tale to his daughter, while his son, who has heard all the tales before, looks away and dreams of what he will do when he grows up. Old Tales, Young Dreams.

I was fascinated by the silhouette of the Pier seen against the sparkling light on the sea, and engaged by the domestic scene in the foreground.

©Henry Hagger 2018
